README.md
flipperzero-i2ctools
Original link Set of i2c tools for Flipper Zero
Wiring
C0 -> SCL
C1 -> SDA
GND -> GND
/!\ Target must use 3v3 logic levels. If you not sure use an i2c isolator like ISO1541
Tools
Scanner
Look for i2c peripherals adresses
Sniffer
Spy i2c traffic
Sender
Send command to i2c peripherals and read result
TODO
- Read more than 2 bytes in sender mode
- Add 10-bits adresses support
- Test with rate > 100khz
- Save records
- Play from files
- Kicad module
- Improve UI
- Refactor Event Management Code
- Add Documentation
- Remove max data size
- Remove max frames read size
