@@ -8,48 +8,39 @@
|
|
|
#include "../helpers/camera_suite_speaker.h"
|
|
|
#include "../helpers/camera_suite_led.h"
|
|
|
|
|
|
-static CameraSuiteViewCamera* current_instance = NULL;
|
|
|
-
|
|
|
-struct CameraSuiteViewCamera {
|
|
|
- CameraSuiteViewCameraCallback callback;
|
|
|
- FuriStreamBuffer* rx_stream;
|
|
|
- FuriThread* worker_thread;
|
|
|
- View* view;
|
|
|
- void* context;
|
|
|
-};
|
|
|
-
|
|
|
-void camera_suite_view_camera_set_callback(
|
|
|
- CameraSuiteViewCamera* instance,
|
|
|
- CameraSuiteViewCameraCallback callback,
|
|
|
- void* context) {
|
|
|
- furi_assert(instance);
|
|
|
- furi_assert(callback);
|
|
|
- instance->callback = callback;
|
|
|
- instance->context = context;
|
|
|
-}
|
|
|
-
|
|
|
-// Function to draw pixels on the canvas based on camera orientation
|
|
|
static void draw_pixel_by_orientation(Canvas* canvas, uint8_t x, uint8_t y, uint8_t orientation) {
|
|
|
+ furi_assert(canvas);
|
|
|
+ furi_assert(x);
|
|
|
+ furi_assert(y);
|
|
|
+ furi_assert(orientation);
|
|
|
+
|
|
|
switch(orientation) {
|
|
|
- case 0: // Camera rotated 0 degrees (right side up, default)
|
|
|
+ default:
|
|
|
+ case 0: { // Camera rotated 0 degrees (right side up, default)
|
|
|
canvas_draw_dot(canvas, x, y);
|
|
|
break;
|
|
|
- case 1: // Camera rotated 90 degrees
|
|
|
+ }
|
|
|
+ case 1: { // Camera rotated 90 degrees
|
|
|
+
|
|
|
canvas_draw_dot(canvas, y, FRAME_WIDTH - 1 - x);
|
|
|
break;
|
|
|
- case 2: // Camera rotated 180 degrees (upside down)
|
|
|
+ }
|
|
|
+ case 2: { // Camera rotated 180 degrees (upside down)
|
|
|
canvas_draw_dot(canvas, FRAME_WIDTH - 1 - x, FRAME_HEIGHT - 1 - y);
|
|
|
break;
|
|
|
- case 3: // Camera rotated 270 degrees
|
|
|
+ }
|
|
|
+ case 3: { // Camera rotated 270 degrees
|
|
|
canvas_draw_dot(canvas, FRAME_HEIGHT - 1 - y, x);
|
|
|
break;
|
|
|
- default:
|
|
|
- break;
|
|
|
+ }
|
|
|
}
|
|
|
}
|
|
|
|
|
|
-static void camera_suite_view_camera_draw(Canvas* canvas, void* _model) {
|
|
|
- UartDumpModel* model = _model;
|
|
|
+static void camera_suite_view_camera_draw(Canvas* canvas, void* model) {
|
|
|
+ furi_assert(canvas);
|
|
|
+ furi_assert(model);
|
|
|
+
|
|
|
+ UartDumpModel* uartDumpModel = model;
|
|
|
|
|
|
// Clear the screen.
|
|
|
canvas_set_color(canvas, ColorBlack);
|
|
|
@@ -57,21 +48,19 @@ static void camera_suite_view_camera_draw(Canvas* canvas, void* _model) {
|
|
|
// Draw the frame.
|
|
|
canvas_draw_frame(canvas, 0, 0, FRAME_WIDTH, FRAME_HEIGHT);
|
|
|
|
|
|
- CameraSuite* app = current_instance->context;
|
|
|
-
|
|
|
for(size_t p = 0; p < FRAME_BUFFER_LENGTH; ++p) {
|
|
|
uint8_t x = p % ROW_BUFFER_LENGTH; // 0 .. 15
|
|
|
uint8_t y = p / ROW_BUFFER_LENGTH; // 0 .. 63
|
|
|
|
|
|
for(uint8_t i = 0; i < 8; ++i) {
|
|
|
- if((model->pixels[p] & (1 << (7 - i))) != 0) {
|
|
|
- draw_pixel_by_orientation(canvas, (x * 8) + i, y, app->orientation);
|
|
|
+ if((uartDumpModel->pixels[p] & (1 << (7 - i))) != 0) {
|
|
|
+ draw_pixel_by_orientation(canvas, (x * 8) + i, y, uartDumpModel->orientation);
|
|
|
}
|
|
|
}
|
|
|
}
|
|
|
|
|
|
// Draw the guide if the camera is not initialized.
|
|
|
- if(!model->initialized) {
|
|
|
+ if(!uartDumpModel->initialized) {
|
|
|
canvas_draw_icon(canvas, 74, 16, &I_DolphinCommon_56x48);
|
|
|
canvas_set_font(canvas, FontSecondary);
|
|
|
canvas_draw_str(canvas, 8, 12, "Connect the ESP32-CAM");
|
|
|
@@ -82,15 +71,106 @@ static void camera_suite_view_camera_draw(Canvas* canvas, void* _model) {
|
|
|
}
|
|
|
}
|
|
|
|
|
|
-static void camera_suite_view_camera_model_init(UartDumpModel* const model) {
|
|
|
+static void save_image(void* model) {
|
|
|
+ furi_assert(model);
|
|
|
+
|
|
|
+ UartDumpModel* uartDumpModel = model;
|
|
|
+
|
|
|
+ // This pointer is used to access the storage.
|
|
|
+ Storage* storage = furi_record_open(RECORD_STORAGE);
|
|
|
+
|
|
|
+ // This pointer is used to access the filesystem.
|
|
|
+ File* file = storage_file_alloc(storage);
|
|
|
+
|
|
|
+ // Store path in local variable.
|
|
|
+ const char* folderName = EXT_PATH("DCIM");
|
|
|
+
|
|
|
+ // Create the folder name for the image file if it does not exist.
|
|
|
+ if(storage_common_stat(storage, folderName, NULL) == FSE_NOT_EXIST) {
|
|
|
+ storage_simply_mkdir(storage, folderName);
|
|
|
+ }
|
|
|
+
|
|
|
+ // This pointer is used to access the file name.
|
|
|
+ FuriString* file_name = furi_string_alloc();
|
|
|
+
|
|
|
+ // Get the current date and time.
|
|
|
+ FuriHalRtcDateTime datetime = {0};
|
|
|
+ furi_hal_rtc_get_datetime(&datetime);
|
|
|
+
|
|
|
+ // Create the file name.
|
|
|
+ furi_string_printf(
|
|
|
+ file_name,
|
|
|
+ EXT_PATH("DCIM/%.4d%.2d%.2d-%.2d%.2d%.2d.bmp"),
|
|
|
+ datetime.year,
|
|
|
+ datetime.month,
|
|
|
+ datetime.day,
|
|
|
+ datetime.hour,
|
|
|
+ datetime.minute,
|
|
|
+ datetime.second);
|
|
|
+
|
|
|
+ // Open the file for writing. If the file does not exist (it shouldn't),
|
|
|
+ // create it.
|
|
|
+ bool result =
|
|
|
+ storage_file_open(file, furi_string_get_cstr(file_name), FSAM_WRITE, FSOM_OPEN_ALWAYS);
|
|
|
+
|
|
|
+ // Free the file name after use.
|
|
|
+ furi_string_free(file_name);
|
|
|
+
|
|
|
+ if(!uartDumpModel->inverted) {
|
|
|
+ for(size_t i = 0; i < FRAME_BUFFER_LENGTH; ++i) {
|
|
|
+ uartDumpModel->pixels[i] = ~uartDumpModel->pixels[i];
|
|
|
+ }
|
|
|
+ }
|
|
|
+
|
|
|
+ // If the file was opened successfully, write the bitmap header and the
|
|
|
+ // image data.
|
|
|
+ if(result) {
|
|
|
+ // Write BMP Header
|
|
|
+ storage_file_write(file, bitmap_header, BITMAP_HEADER_LENGTH);
|
|
|
+
|
|
|
+ // @todo - Add a function for saving the image directly from the
|
|
|
+ // ESP32-CAM to the Flipper Zero SD card.
|
|
|
+
|
|
|
+ // Write locally to the Flipper Zero SD card in the DCIM folder.
|
|
|
+ int8_t row_buffer[ROW_BUFFER_LENGTH];
|
|
|
+
|
|
|
+ // @todo - Save image based on orientation.
|
|
|
+ for(size_t i = 64; i > 0; --i) {
|
|
|
+ for(size_t j = 0; j < ROW_BUFFER_LENGTH; ++j) {
|
|
|
+ row_buffer[j] = uartDumpModel->pixels[((i - 1) * ROW_BUFFER_LENGTH) + j];
|
|
|
+ }
|
|
|
+ storage_file_write(file, row_buffer, ROW_BUFFER_LENGTH);
|
|
|
+ }
|
|
|
+ }
|
|
|
+
|
|
|
+ // Close the file.
|
|
|
+ storage_file_close(file);
|
|
|
+
|
|
|
+ // Free up memory.
|
|
|
+ storage_file_free(file);
|
|
|
+}
|
|
|
+
|
|
|
+static void
|
|
|
+ camera_suite_view_camera_model_init(UartDumpModel* const model, CameraSuite* instance_context) {
|
|
|
+ furi_assert(model);
|
|
|
+ furi_assert(instance_context);
|
|
|
+
|
|
|
for(size_t i = 0; i < FRAME_BUFFER_LENGTH; i++) {
|
|
|
model->pixels[i] = 0;
|
|
|
}
|
|
|
+
|
|
|
+ uint32_t orientation = instance_context->orientation;
|
|
|
+ model->flash = instance_context->flash;
|
|
|
+ model->inverted = false;
|
|
|
+ model->orientation = orientation;
|
|
|
}
|
|
|
|
|
|
static bool camera_suite_view_camera_input(InputEvent* event, void* context) {
|
|
|
furi_assert(context);
|
|
|
+ furi_assert(event);
|
|
|
+
|
|
|
CameraSuiteViewCamera* instance = context;
|
|
|
+
|
|
|
if(event->type == InputTypeRelease) {
|
|
|
switch(event->key) {
|
|
|
default: // Stop all sounds, reset the LED.
|
|
|
@@ -106,13 +186,18 @@ static bool camera_suite_view_camera_input(InputEvent* event, void* context) {
|
|
|
true);
|
|
|
break;
|
|
|
}
|
|
|
- // Send `data` to the ESP32-CAM
|
|
|
} else if(event->type == InputTypePress) {
|
|
|
- uint8_t data[1];
|
|
|
+ uint8_t data[1] = {'X'};
|
|
|
switch(event->key) {
|
|
|
- case InputKeyBack:
|
|
|
- // Stop the camera stream.
|
|
|
- data[0] = 's';
|
|
|
+ // Camera: Stop stream.
|
|
|
+ case InputKeyBack: {
|
|
|
+ // Set the camera flash to off.
|
|
|
+ uint8_t flash_off = 'f';
|
|
|
+ furi_hal_uart_tx(FuriHalUartIdUSART1, &flash_off, 1);
|
|
|
+ furi_delay_ms(50);
|
|
|
+ // Stop camera stream.
|
|
|
+ uint8_t stop_camera = 's';
|
|
|
+ furi_hal_uart_tx(FuriHalUartIdUSART1, &stop_camera, 1);
|
|
|
// Go back to the main menu.
|
|
|
with_view_model(
|
|
|
instance->view,
|
|
|
@@ -123,9 +208,9 @@ static bool camera_suite_view_camera_input(InputEvent* event, void* context) {
|
|
|
},
|
|
|
true);
|
|
|
break;
|
|
|
- case InputKeyLeft:
|
|
|
- // Camera: Invert.
|
|
|
- data[0] = '<';
|
|
|
+ }
|
|
|
+ // Camera: Toggle invert on the ESP32-CAM.
|
|
|
+ case InputKeyLeft: {
|
|
|
with_view_model(
|
|
|
instance->view,
|
|
|
UartDumpModel * model,
|
|
|
@@ -134,12 +219,20 @@ static bool camera_suite_view_camera_input(InputEvent* event, void* context) {
|
|
|
camera_suite_play_happy_bump(instance->context);
|
|
|
camera_suite_play_input_sound(instance->context);
|
|
|
camera_suite_led_set_rgb(instance->context, 0, 0, 255);
|
|
|
+ if(model->inverted) {
|
|
|
+ data[0] = 'i';
|
|
|
+ model->inverted = false;
|
|
|
+ } else {
|
|
|
+ data[0] = 'I';
|
|
|
+ model->inverted = true;
|
|
|
+ }
|
|
|
instance->callback(CameraSuiteCustomEventSceneCameraLeft, instance->context);
|
|
|
},
|
|
|
true);
|
|
|
break;
|
|
|
- case InputKeyRight:
|
|
|
- // Camera: Enable/disable dithering.
|
|
|
+ }
|
|
|
+ // Camera: Enable/disable dithering.
|
|
|
+ case InputKeyRight: {
|
|
|
data[0] = '>';
|
|
|
with_view_model(
|
|
|
instance->view,
|
|
|
@@ -153,8 +246,9 @@ static bool camera_suite_view_camera_input(InputEvent* event, void* context) {
|
|
|
},
|
|
|
true);
|
|
|
break;
|
|
|
- case InputKeyUp:
|
|
|
- // Camera: Increase contrast.
|
|
|
+ }
|
|
|
+ // Camera: Increase contrast.
|
|
|
+ case InputKeyUp: {
|
|
|
data[0] = 'C';
|
|
|
with_view_model(
|
|
|
instance->view,
|
|
|
@@ -168,8 +262,9 @@ static bool camera_suite_view_camera_input(InputEvent* event, void* context) {
|
|
|
},
|
|
|
true);
|
|
|
break;
|
|
|
- case InputKeyDown:
|
|
|
- // Camera: Reduce contrast.
|
|
|
+ }
|
|
|
+ // Camera: Reduce contrast.
|
|
|
+ case InputKeyDown: {
|
|
|
data[0] = 'c';
|
|
|
with_view_model(
|
|
|
instance->view,
|
|
|
@@ -183,58 +278,113 @@ static bool camera_suite_view_camera_input(InputEvent* event, void* context) {
|
|
|
},
|
|
|
true);
|
|
|
break;
|
|
|
- case InputKeyOk:
|
|
|
- // Switch dithering types.
|
|
|
- data[0] = 'D';
|
|
|
+ }
|
|
|
+ // Camera: Take picture.
|
|
|
+ case InputKeyOk: {
|
|
|
with_view_model(
|
|
|
instance->view,
|
|
|
UartDumpModel * model,
|
|
|
{
|
|
|
- UNUSED(model);
|
|
|
- camera_suite_play_happy_bump(instance->context);
|
|
|
+ camera_suite_play_long_bump(instance->context);
|
|
|
camera_suite_play_input_sound(instance->context);
|
|
|
camera_suite_led_set_rgb(instance->context, 0, 0, 255);
|
|
|
+
|
|
|
+ // Save picture directly to ESP32-CAM.
|
|
|
+ // @todo - Add this functionality.
|
|
|
+ // data[0] = 'P';
|
|
|
+ // furi_hal_uart_tx(FuriHalUartIdUSART1, data, 1);
|
|
|
+
|
|
|
+ // if(model->flash) {
|
|
|
+ // data[0] = 'F';
|
|
|
+ // furi_hal_uart_tx(FuriHalUartIdUSART1, data, 1);
|
|
|
+ // furi_delay_ms(50);
|
|
|
+ // }
|
|
|
+
|
|
|
+ // Take a picture.
|
|
|
+ save_image(model);
|
|
|
+
|
|
|
+ // if(model->flash) {
|
|
|
+ // data[0] = 'f';
|
|
|
+ // }
|
|
|
instance->callback(CameraSuiteCustomEventSceneCameraOk, instance->context);
|
|
|
},
|
|
|
true);
|
|
|
break;
|
|
|
+ }
|
|
|
+ // Camera: Do nothing.
|
|
|
case InputKeyMAX:
|
|
|
+ default: {
|
|
|
break;
|
|
|
}
|
|
|
- // Send `data` to the ESP32-CAM
|
|
|
- furi_hal_uart_tx(FuriHalUartIdUSART1, data, 1);
|
|
|
+ }
|
|
|
+
|
|
|
+ if(data[0] != 'X') {
|
|
|
+ // Send `data` to the ESP32-CAM.
|
|
|
+ furi_hal_uart_tx(FuriHalUartIdUSART1, data, 1);
|
|
|
+ }
|
|
|
}
|
|
|
return true;
|
|
|
}
|
|
|
|
|
|
static void camera_suite_view_camera_exit(void* context) {
|
|
|
- furi_assert(context);
|
|
|
+ UNUSED(context);
|
|
|
+
|
|
|
+ // Set the camera flash to off.
|
|
|
+ uint8_t flash_off = 'f';
|
|
|
+ furi_hal_uart_tx(FuriHalUartIdUSART1, &flash_off, 1);
|
|
|
+ furi_delay_ms(50);
|
|
|
+
|
|
|
+ // Stop camera stream.
|
|
|
+ uint8_t stop_camera = 's';
|
|
|
+ furi_hal_uart_tx(FuriHalUartIdUSART1, &stop_camera, 1);
|
|
|
+ furi_delay_ms(50);
|
|
|
}
|
|
|
|
|
|
static void camera_suite_view_camera_enter(void* context) {
|
|
|
- // Check `context` for null. If it is null, abort program, else continue.
|
|
|
furi_assert(context);
|
|
|
|
|
|
- // Cast `context` to `CameraSuiteViewCamera*` and store it in `instance`.
|
|
|
+ // Get the camera suite instance context.
|
|
|
CameraSuiteViewCamera* instance = (CameraSuiteViewCamera*)context;
|
|
|
|
|
|
- // Assign the current instance to the global variable
|
|
|
- current_instance = instance;
|
|
|
+ // Get the camera suite instance context.
|
|
|
+ CameraSuite* instance_context = instance->context;
|
|
|
+
|
|
|
+ // Start camera stream.
|
|
|
+ uint8_t start_camera = 'S';
|
|
|
+ furi_hal_uart_tx(FuriHalUartIdUSART1, &start_camera, 1);
|
|
|
+ furi_delay_ms(75);
|
|
|
+
|
|
|
+ // Get/set dither type.
|
|
|
+ uint8_t dither_type = instance_context->dither;
|
|
|
+ furi_hal_uart_tx(FuriHalUartIdUSART1, &dither_type, 1);
|
|
|
+ furi_delay_ms(75);
|
|
|
|
|
|
- uint8_t data[1];
|
|
|
- data[0] = 'S'; // Uppercase `S` to start the camera
|
|
|
- // Send `data` to the ESP32-CAM
|
|
|
- furi_hal_uart_tx(FuriHalUartIdUSART1, data, 1);
|
|
|
+ // Make sure the camera is not inverted.
|
|
|
+ uint8_t invert_camera = 'i';
|
|
|
+ furi_hal_uart_tx(FuriHalUartIdUSART1, &invert_camera, 1);
|
|
|
+ furi_delay_ms(75);
|
|
|
+
|
|
|
+ // Toggle flash on or off based on the current state. This will keep the
|
|
|
+ // flash on initially. However we're toggling it for now on input.
|
|
|
+ uint8_t flash_state = instance_context->flash ? 'F' : 'f';
|
|
|
+ furi_hal_uart_tx(FuriHalUartIdUSART1, &flash_state, 1);
|
|
|
+ furi_delay_ms(75);
|
|
|
+
|
|
|
+ // Make sure we start with the flash off.
|
|
|
+ // uint8_t flash_state = 'f';
|
|
|
+ // furi_hal_uart_tx(FuriHalUartIdUSART1, &flash_state, 1);
|
|
|
+ // furi_delay_ms(75);
|
|
|
|
|
|
with_view_model(
|
|
|
instance->view,
|
|
|
UartDumpModel * model,
|
|
|
- { camera_suite_view_camera_model_init(model); },
|
|
|
+ { camera_suite_view_camera_model_init(model, instance_context); },
|
|
|
true);
|
|
|
}
|
|
|
|
|
|
static void camera_on_irq_cb(UartIrqEvent uartIrqEvent, uint8_t data, void* context) {
|
|
|
- // Check `context` for null. If it is null, abort program, else continue.
|
|
|
+ furi_assert(uartIrqEvent);
|
|
|
+ furi_assert(data);
|
|
|
furi_assert(context);
|
|
|
|
|
|
// Cast `context` to `CameraSuiteViewCamera*` and store it in `instance`.
|
|
|
@@ -248,47 +398,57 @@ static void camera_on_irq_cb(UartIrqEvent uartIrqEvent, uint8_t data, void* cont
|
|
|
}
|
|
|
}
|
|
|
|
|
|
-static void process_ringbuffer(UartDumpModel* model, uint8_t byte) {
|
|
|
- // First char has to be 'Y' in the buffer.
|
|
|
- if(model->ringbuffer_index == 0 && byte != 'Y') {
|
|
|
- return;
|
|
|
- }
|
|
|
+static void process_ringbuffer(UartDumpModel* model, uint8_t const byte) {
|
|
|
+ furi_assert(model);
|
|
|
+ furi_assert(byte);
|
|
|
|
|
|
- // Second char has to be ':' in the buffer or reset.
|
|
|
- if(model->ringbuffer_index == 1 && byte != ':') {
|
|
|
- model->ringbuffer_index = 0;
|
|
|
- process_ringbuffer(model, byte);
|
|
|
+ // The first HEADER_LENGTH bytes are reserved for header information.
|
|
|
+ if(model->ringbuffer_index < HEADER_LENGTH) {
|
|
|
+ // Validate the start of row characters 'Y' and ':'.
|
|
|
+ if(model->ringbuffer_index == 0 && byte != 'Y') {
|
|
|
+ // Incorrect start of frame; reset.
|
|
|
+ return;
|
|
|
+ }
|
|
|
+ if(model->ringbuffer_index == 1 && byte != ':') {
|
|
|
+ // Incorrect start of frame; reset.
|
|
|
+ model->ringbuffer_index = 0;
|
|
|
+ return;
|
|
|
+ }
|
|
|
+ if(model->ringbuffer_index == 2) {
|
|
|
+ // Assign the third byte as the row identifier.
|
|
|
+ model->row_identifier = byte;
|
|
|
+ }
|
|
|
+ model->ringbuffer_index++; // Increment index for the next byte.
|
|
|
return;
|
|
|
}
|
|
|
|
|
|
- // Assign current byte to the ringbuffer.
|
|
|
- model->row_ringbuffer[model->ringbuffer_index] = byte;
|
|
|
- // Increment the ringbuffer index.
|
|
|
- ++model->ringbuffer_index;
|
|
|
+ // Store pixel value directly after the header.
|
|
|
+ model->row_ringbuffer[model->ringbuffer_index - HEADER_LENGTH] = byte;
|
|
|
+ model->ringbuffer_index++; // Increment index for the next byte.
|
|
|
|
|
|
- // Let's wait 'till the buffer fills.
|
|
|
- if(model->ringbuffer_index < RING_BUFFER_LENGTH) {
|
|
|
- return;
|
|
|
- }
|
|
|
+ // Check whether the ring buffer is filled.
|
|
|
+ if(model->ringbuffer_index >= RING_BUFFER_LENGTH) {
|
|
|
+ model->ringbuffer_index = 0; // Reset the ring buffer index.
|
|
|
+ model->initialized = true; // Set the connection as successfully established.
|
|
|
|
|
|
- // Flush the ringbuffer to the framebuffer.
|
|
|
- model->ringbuffer_index = 0; // Reset the ringbuffer
|
|
|
- model->initialized = true; // Established the connection successfully.
|
|
|
- size_t row_start_index =
|
|
|
- model->row_ringbuffer[2] * ROW_BUFFER_LENGTH; // Third char will determine the row number
|
|
|
+ // Compute the starting index for the row in the pixel buffer.
|
|
|
+ size_t row_start_index = model->row_identifier * ROW_BUFFER_LENGTH;
|
|
|
|
|
|
- if(row_start_index > LAST_ROW_INDEX) { // Failsafe
|
|
|
- row_start_index = 0;
|
|
|
- }
|
|
|
+ // Ensure the row start index is within the valid range.
|
|
|
+ if(row_start_index > LAST_ROW_INDEX) {
|
|
|
+ row_start_index = 0; // Reset to a safe value in case of an overflow.
|
|
|
+ }
|
|
|
|
|
|
- for(size_t i = 0; i < ROW_BUFFER_LENGTH; ++i) {
|
|
|
- model->pixels[row_start_index + i] =
|
|
|
- model->row_ringbuffer[i + 3]; // Writing the remaining 16 bytes into the frame buffer
|
|
|
+ // Flush the contents of the ring buffer to the pixel buffer.
|
|
|
+ for(size_t i = 0; i < ROW_BUFFER_LENGTH; ++i) {
|
|
|
+ model->pixels[row_start_index + i] = model->row_ringbuffer[i];
|
|
|
+ }
|
|
|
}
|
|
|
}
|
|
|
|
|
|
static int32_t camera_worker(void* context) {
|
|
|
furi_assert(context);
|
|
|
+
|
|
|
CameraSuiteViewCamera* instance = context;
|
|
|
|
|
|
while(1) {
|
|
|
@@ -328,32 +488,45 @@ static int32_t camera_worker(void* context) {
|
|
|
}
|
|
|
|
|
|
CameraSuiteViewCamera* camera_suite_view_camera_alloc() {
|
|
|
+ // Allocate memory for the instance
|
|
|
CameraSuiteViewCamera* instance = malloc(sizeof(CameraSuiteViewCamera));
|
|
|
|
|
|
+ // Allocate the view object
|
|
|
instance->view = view_alloc();
|
|
|
|
|
|
+ // Allocate a stream buffer
|
|
|
instance->rx_stream = furi_stream_buffer_alloc(2048, 1);
|
|
|
|
|
|
- // Set up views
|
|
|
+ // Allocate model
|
|
|
view_allocate_model(instance->view, ViewModelTypeLocking, sizeof(UartDumpModel));
|
|
|
- view_set_context(instance->view, instance); // furi_assert crashes in events without this
|
|
|
+
|
|
|
+ // Set context for the view
|
|
|
+ view_set_context(instance->view, instance);
|
|
|
+
|
|
|
+ // Set draw callback
|
|
|
view_set_draw_callback(instance->view, (ViewDrawCallback)camera_suite_view_camera_draw);
|
|
|
+
|
|
|
+ // Set input callback
|
|
|
view_set_input_callback(instance->view, camera_suite_view_camera_input);
|
|
|
+
|
|
|
+ // Set enter callback
|
|
|
view_set_enter_callback(instance->view, camera_suite_view_camera_enter);
|
|
|
- view_set_exit_callback(instance->view, camera_suite_view_camera_exit);
|
|
|
|
|
|
- with_view_model(
|
|
|
- instance->view,
|
|
|
- UartDumpModel * model,
|
|
|
- { camera_suite_view_camera_model_init(model); },
|
|
|
- true);
|
|
|
+ // Set exit callback
|
|
|
+ view_set_exit_callback(instance->view, camera_suite_view_camera_exit);
|
|
|
|
|
|
- instance->worker_thread = furi_thread_alloc_ex("UsbUartWorker", 2048, camera_worker, instance);
|
|
|
+ // Allocate a thread for this camera to run on.
|
|
|
+ FuriThread* thread = furi_thread_alloc_ex("UsbUartWorker", 2048, camera_worker, instance);
|
|
|
+ instance->worker_thread = thread;
|
|
|
furi_thread_start(instance->worker_thread);
|
|
|
|
|
|
// Enable uart listener
|
|
|
furi_hal_console_disable();
|
|
|
+
|
|
|
+ // 115200 is the default baud rate for the ESP32-CAM.
|
|
|
furi_hal_uart_set_br(FuriHalUartIdUSART1, 230400);
|
|
|
+
|
|
|
+ // Enable UART1 and set the IRQ callback.
|
|
|
furi_hal_uart_set_irq_cb(FuriHalUartIdUSART1, camera_on_irq_cb, instance);
|
|
|
|
|
|
return instance;
|
|
|
@@ -362,6 +535,18 @@ CameraSuiteViewCamera* camera_suite_view_camera_alloc() {
|
|
|
void camera_suite_view_camera_free(CameraSuiteViewCamera* instance) {
|
|
|
furi_assert(instance);
|
|
|
|
|
|
+ // Remove the IRQ callback.
|
|
|
+ furi_hal_uart_set_irq_cb(FuriHalUartIdUSART1, NULL, NULL);
|
|
|
+
|
|
|
+ // Free the worker thread.
|
|
|
+ furi_thread_free(instance->worker_thread);
|
|
|
+
|
|
|
+ // Free the allocated stream buffer.
|
|
|
+ furi_stream_buffer_free(instance->rx_stream);
|
|
|
+
|
|
|
+ // Re-enable the console.
|
|
|
+ // furi_hal_console_enable();
|
|
|
+
|
|
|
with_view_model(
|
|
|
instance->view, UartDumpModel * model, { UNUSED(model); }, true);
|
|
|
view_free(instance->view);
|
|
|
@@ -371,4 +556,14 @@ void camera_suite_view_camera_free(CameraSuiteViewCamera* instance) {
|
|
|
View* camera_suite_view_camera_get_view(CameraSuiteViewCamera* instance) {
|
|
|
furi_assert(instance);
|
|
|
return instance->view;
|
|
|
+}
|
|
|
+
|
|
|
+void camera_suite_view_camera_set_callback(
|
|
|
+ CameraSuiteViewCamera* instance,
|
|
|
+ CameraSuiteViewCameraCallback callback,
|
|
|
+ void* context) {
|
|
|
+ furi_assert(instance);
|
|
|
+ furi_assert(callback);
|
|
|
+ instance->callback = callback;
|
|
|
+ instance->context = context;
|
|
|
}
|
MX
